HJS20 Micro-Controller

HJS20 Dual Axis Micro-Controller
Download Data Sheet
Need Something Customized?
Shop Spare Parts
Get A Quote

The HJS20 multi-axis controller is a robust hall sensor switching device for electro-hydraulic applications. It is especially suitable for installation in our ball handles. It is resistant to oil, maritime conditions e.g. offshore / vessels, UV radiation typically from the sun.
Technical details may vary based on configuration or application. Technical data subject to change without notice.

  • Mechanical Life: 5 million cycles
  • Travel Angle: 25° each direction
  • Operating Force: up 3.5N (0.79lb)
  • Operating temperature: -40°C to +85°C
  • Protection: IP67
  • Supply Voltage: 5Vdc
  • Output Voltage: 0.5-4.5Vdc
